Mitre Guides

Hollow Sections, Universal Beams, Columns & Joists -Bevel Across Web

1

One End Square, One End Bevelled

2

Parallel Bevels

3

Same Bevel, Opposite Ways

4

Different Bevel, Opposite Ways

5

Different Bevel, Same Way

Universal Beams, Columns & Joints Bevel Across Flange

6

One End Square, One End Bevelled

7

Parallel Bevels

8

Same Bevel, Opposite Ways

9

Different Bevel, Opposite Ways

10

Different Bevel, Same Way

Angles - Long Point on Back

11

Right-Hand End Square, Left-Hand End Bevelled

12

Left-Hand End Square, Right-Hand End Bevelled

13

Parallel Bevels (Slanting to left)

14

Same Bevel Opposite Ways

15

Different Bevels Opposite Ways (Left-hand end bevel greater than right hand bevel)

16

Different Bevels Opposite Ways (Left-hand end bevel greater than right hand bevel)

17

Different Bevels Opposite Ways (Right-hand end bevel greater than left-hand bevel)(Slanting to left)

18

Different Bevels Same Way (Left-hand end bevel greater than right-hand bevel)(Slanting to left)

Angles - Long Point on Toes

19

Right-Hand End Square, Left-Hand End Bevelled

20

Left-Hand End Square, Right-Hand End Bevelled

21

Parallel Bevels(Slanting to right)

22

Same Bevel Opposite Ways

23

Different Bevels Opposite Ways (Left-hand end bevel greater than right hand bevel)

24

Different Bevels Opposite Ways (Left-hand end bevel greater than right hand bevel)

25

Different Bevels Opposite Ways (Right-hand end bevel greater than left-hand bevel)(Slanting to left)

26

Different Bevels Same Way (Left-hand end bevel greater than right-hand bevel)(Slanting to left)

Channels - Bevel Across Back

27

One End Square, One End Bevelled

28

Parallel Bevels(Slanting to left)

29

Same Bevel, Opposite Ways

30

Different Bevels, Opposite Ways

31

Different Bevels Same Ways (Left-hand end bevel greater than right-hand bevel)(Slanting to left)

32

One End Square, One End Bevelled

33

Parallel Bevels(Slanting to left)

34

Different Bevels, Opposite Ways

35

Different Bevels Same Ways(Left-hand end bevel greater than right-hand bevel)(Slanting to left)

Channels - Bevel Across Legs, Long Point on Back

36

One End Square, One End Bevelled

37

Parallel Bevels(Slanting to left)

38

Same Bevel, Opposite Ways

39

Different Bevels, Opposite Ways

40

Different Bevels, Same Way

Channels - Bevel Across Legs, Long Point on Toes

41

One End Square, One End Bevelled

42

Same Bevel, Opposite Ways

43

Different Bevels, Opposite Ways

44

Different Bevels, Same Way

Weight Guide

For Guidance: Size of Plates and weights (KGS)

MM 2000x1000 2500x1250 3000x1500 4000x2000 6000x2000 8000x2000 12000x2000 5000x2500 6000x2500
3 47 74 106 188 283 377 565 294 353
4 63 98 141 251 377 502 754 393 471
5 79 123 177 314 471 628 942 491 589
6 94 147 212 377 565 754 1130 589 707
6.5 102 159 230 408 612 816 1225 638 765
7 110 172 247 440 659 879 1319 687 824
8 126 196 283 502 754 1005 1507 785 942
9 141 221 318 565 848 1130 1696 883 1060
10 157 245 353 628 942 1256 1884 981 1178
11 173 270 389 691 1036 1382 2072 1079 1295
12 188 294 424 754 1130 1507 2261 1178 1413
12.5 196 307 442 785 1178 1570 2355 1227 1472
15 236 368 530 942 1413 1884 2826 1472 1766
16 251 393 565 1005 1507 2010 3014 1570 1884
18 283 442 636 1130 1696 2261 3391 1766 2120
20 314 491 707 1256 1884 2512 3768 1963 2355
22 345 540 777 1382 2072 2763 4145 2159 2591
25 393 613 883 1570 2355 3140 4710 2453 2944
30 471 736 1060 1884 2826 3768 5652 2944 3533
35 550 859 1236 2198 3297 4396 6594 3434 4121
40 628 981 1413 2512 3768 5024 7536 3925 4710
45 707 1104 1590 2826 4239 5652 8478 4416 5299
50 785 1227 1766 3140 4710 6280 9420 4906 5888
60 942 1472 2120 3768 5652 7536 11304 5888 7065
65 1021 1595 2296 4082 6123 8164 12246 6378 7654
70 1099 1717 2473 4396 6594 8792 13188 6869 8243
75 1178 1840 2649 4710 7065 9420 14130 7359 8831
80 1256 1963 2826 5024 7536 10048 15072 7850 9420
90 1413 2208 3179 5652 8478 11304 16956 8831 10598
100 1570 2453 3533 6280 9420 12560 18840 9813 11775
